T10-5583 GPS Module with QMC5883L Compass/GPS Active Antenna Support GPS BDS Galileo SBAS QZSS for Arduino Flight Controller RC Plane FPV Quadcopter & Drone

Description: M10-5883: Chip: M10050 (tenth generation chip) Working Mode: GPS, BDS, GALILEO, SBAS, QZSS Baud Rate: 4800bps-921600bps, default is 38400bps Voltage: DC3.6V-5.5V, typical is 5.0V Current: 15mA/5.0V Size: 22*20*6.2mm Weight: 5.8g Connector: 1.0 pitch 6pin socket T10-583: Chip: BT-16CYJ Working Mode: GPS, BDS, GALILEO Baud Rate: 9600bps-2000000bps, default is 115200bps, support sleep mode Voltage: DC3.6V-5.5V, typical is 5.0V Current: 20mA/5.0V Size: 22*20*8.1mm Weight: 8.5g Connector: 1.0 pitch 6pin socket

• GPS module is used BT-16CYJ chip design, which can be rapid position 25 areas and more in 25s, fast, stable and accurate position
• No matter what you are using in GPS, BDS, Galileo, this GPS module will give you a fast response for the position in any area
• Equipped with TX light and PPS light. When you power, the TX light will flash blue light, which means this is data output. After 3D positioning, PPS light will start to flash red light
• The internal compass of the GPS module is QMC5883L. It is support DC3.6V~5.5V input and TTL level output
• The refresh frequency is 1Hz~20Hz, BK1661S only support is 1Hz. Come with FLASH, you can use U-center to set GPS parameters without losing it during power off
• The size of mini GPS module is 22*20*8.1mm, weighs 8.5g. The connector is 1.0 pitch 6 pin socket
